1756-M22 1756M22 Allen Bradley ControlLogix Logix5555 Moduł pamięci nieulotnej
⇒ Kliknij tutaj, aby uzyskać dobrą cenę 1756-M22
Marka / producent | AB / USA |
Numer części |
1756-M22 |
Alternatywny numer części | 1756-M22 |
Opis | MOTOR SERVO |
Wymiary |
18 x 12,6 x 12 cm |
Waga | 0,7 kg |
Szczegóły Produktu
The AB 1756-M22 module is a 750 KB non-volatile memory module for AB ControlLogix 5555 controllers. Moduł AB 1756-M22 jest nieulotnym modułem pamięci o pojemności 750 KB dla kontrolerów AB ControlLogix 5555. ControlLogix controllers with which the 1756-M22 module is compatible include the 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23, and the 1756-L55M24 controllers. Kontrolery ControlLogix, z którymi moduł 1756-M22 jest kompatybilny, obejmują kontrolery 1756-L55, 1756-L55M12, 1756-L55M13, 1756-L55M14, 1756-L55M16, 1756-L55M22, 1756-L55M23 i 1756-L55M24. Firmware version 10.x or later is required to be used on the controllers for them to work with the 1756-M22 memory module. Oprogramowanie wewnętrzne w wersji 10.x lub nowszej musi być używane w sterownikach, aby mogły współpracować z modułem pamięci 1756-M22. If the controllers have an older firmware version, the controller firmware must be upgraded prior to memory module installation. Jeśli kontrolery mają starszą wersję oprogramowania układowego, oprogramowanie układowe sterownika musi zostać zaktualizowane przed instalacją modułu pamięci. To prevent damage to the memory module, the battery must be disconnected from the controller before installing or replacing the memory module. Aby zapobiec uszkodzeniu modułu pamięci, przed instalacją lub wymianą modułu pamięci należy odłączyć akumulator od kontrolera. The installation or replacement of the 1756-M22 module on the ControlLogix 5555 controller requires the following 4 steps: removing the side plate of the controller, removing the existing memory board, installing the new memory board, and replacing the controller side plate. Instalacja lub wymiana modułu 1756-M22 w kontrolerze ControlLogix 5555 wymaga 4 następujących kroków: usunięcie płyty bocznej kontrolera, usunięcie istniejącej płyty pamięci, instalacja nowej płyty pamięci i wymiana płyty bocznej kontrolera. Labels can be placed on the side of the controller to identify the type of memory board that is installed. Z boku kontrolera można umieścić etykiety identyfikujące typ zainstalowanej karty pamięci.
The 1756-M22 module is sensitive to ESD. Moduł 1756-M22 jest wrażliwy na wyładowania elektrostatyczne. The following precautions need to be followed to prevent damage to the module: touching a grounded object to discharge static, wearing a grounded wrist strap, avoiding touching the connector or module components, using static-safe workstations, and storing the module in static-safe containers. Aby zapobiec uszkodzeniu modułu, należy przestrzegać następujących środków ostrożności: dotknięcie uziemionego przedmiotu w celu rozładowania elektryczności, noszenie uziemionego paska na nadgarstek, unikanie dotykania złącza lub elementów modułu, korzystanie ze stacji roboczych odpornych na ładunki elektrostatyczne i przechowywanie modułu w stanie statycznym pojemniki The operating temperature range for the 1756-M22 module is from 0 to 60 degrees Celsius. Zakres temperatur pracy modułu 1756-M22 wynosi od 0 do 60 stopni Celsjusza. The storage temperature range for the module is from -40 to 85 degrees Celsius. Zakres temperatur przechowywania modułu wynosi od -40 do 85 stopni Celsjusza. The range for the relative humidity is from 5 to 95% (non-condensing). Zakres wilgotności względnej wynosi od 5 do 95% (bez kondensacji). The operating and non-operating shock ratings for the module are 30 G and 50 G, respectively. Szok operacyjny i nieoperacyjny dla modułu wynoszą odpowiednio 30 G i 50 G. The enclosure of the module is open and it complies with the T4 North American temperature code and the T4 IEC temperature code. Obudowa modułu jest otwarta i jest zgodna z kodem temperatury T4 w Ameryce Północnej i kodem temperatury T4 IEC.
Nasze usługi
100% pełna Nowość - Oryginalna pieczęć fabryczna
Gwarancja: 12 miesięcy
Opakowanie: oryginalne opakowanie z kartonami
Czas dostawy: Wysyłka w ciągu 3 dni po dokonaniu płatności
